490-05
Dirt cover and locking ring for BAIO® spigot ends

Hydrants, air valve sets and pipe fittings (e.g. flanged spigots, SM-fittings, ...) with BAIO® spigot ends installed in vertical position shall be secured against unintentional unlocking using the dirt cover and locking ring.

read more reduce
Material: Locking ring: GJS-500, Hawle epoxy powder coated
Rubber sleeve: NBR
Max. operating Pressure: Sewage water: 16 bar
Potable water: 16 bar
Medium Water / Sewage

Hydrants, air valve sets and pipe fittings (e.g. flanged spigots, SM-fittings, ...) with BAIO® spigot ends installed in vertical position shall be secured against unintentional unlocking using the dirt cover and locking ring.

Contacts
Wish List
Order Nr.

DN
Operating pressure max.
L

B
D
H
 Medium Weight Specification Basket
4900800800
 80 16 bar 35 mm 160 mm 95 mm 157,5 mm 0,42 kg
4900800809
 80 16 bar 35 mm 160 mm 95 mm 157,5 mm 0,42 kg
Wish List

Required in case of vertical BAIO® integrations (e.g., hydrants, air valve sets).
