Please note: for DN 80 and DN 100 use extension spindle and handwheel DN 50
-
Factory preinstalled BAIO® lip gasket (BLD®) for DCI pipes
-
For plastic pipe installation, please mention on order from GKS gasket
-
When PE pipes are connected, support liners must be used.
480-00
Sewage water knife gate valve with sockets - BAIO® system
| Material: |
Body: GJS-400, Hawle epoxy powder coated Spindle, shut-off blade: stainless steel O-ring gasket set: POM/NBR |
|---|---|
| Max. operating Pressure: | Sewage water: 10 bar |
| Medium | Sewage |
Sewage water knife gate valve for buried installation with two BAIO® double function sockets for the restraint connection with BAIO® spigot ends and for connecting DCI, steel, PE and PVC pipes.
The reliable and tight shut-off function is ensured via a shut-off blade of hard-rolled stainless steel and an O-ring gasket package. The gasket package prevents solids from sticking to the spindle and, in case of repair, permits the exchange of the valve bonnet without taking the pressure line out of service.
Gaskets:
DCI pipes: BLD® gasket
PE/PVC pipes: GKS gasket
Square of spindel: 14,3 mm
|
Order Nr.
|
DN |
L |
B |
H |
Square of spindle |
Medium | Weight | Specification | Basket |
|---|---|---|---|---|---|---|---|---|---|
|
4800800020
|
80 | 300 mm | 163 mm | 367 mm | 14,3 mm | 14,65 kg | |||
|
4801000020
|
100 | 350 mm | 201 mm | 414 mm | 14,3 mm | 19,90 kg |
|
Technical Documents
|
|---|
| Declaration of conformity - Sewage Gate Valves 480, 481, 482 |
